CRUX SWRFD-60E Radio Replacement Interface with Steering Wheel Control Retention Compatible Fit Select Ford Vehicles with 4" Factory Screen

Upgrade the factory radio in select Ford vehicles equipped with a 4-inch factory display using the CRUX SWRFD-60E radio replacement interface. Designed for compatible aftermarket stereo installations, the SWRFD-60E retains the factory 4" display, steering wheel audio controls, factory AUX input, retained accessory power, and select voice and phone-button functions while providing important navigation outputs.

General Features

• CRUX SWRFD-60E Radio Replacement Interface

• Designed for Select Ford Vehicles with 4" Factory Screen

• Designed for Aftermarket Radio Installation

• Retains Factory 4" Display Screen

• Retains Factory Steering Wheel Audio Controls

• Built-In Pre-Programmed Steering Wheel Control Interface

• Retains Factory AUX-IN Jack

• Retains R.A.P. – Retained Accessory Power

• Provides 12-Volt Accessory Power

• Accessory Output Rated up to 10 Amps

• Provides Parking Brake Output

• Provides Reverse Gear Output

• Provides Vehicle Speed Signal (VSS)

• Compatible with Supported Amplified Systems

• Compatible with Supported Non-Amplified Systems

• Retains Select Voice Command Functions in Vehicles Equipped with SYNC

• Retains Compatible Phone Pick-Up & Hang-Up Functions Through Steering Wheel Controls

• Micro-B USB Updatable

• 1-Year Manufacturer Warranty

Factory 4" Screen Retention

One of the key features of the SWRFD-60E is its ability to retain the compatible Ford factory 4-inch display after replacing the original radio.

• Retains Factory 4" Display

• Designed Specifically for Compatible 4" Screen Applications

• Helps Maintain Factory Display Integration

• Allows Installation of a Compatible Aftermarket Stereo

Steering Wheel Control Retention

The SWRFD-60E includes a built-in, pre-programmed interface designed to retain compatible factory steering wheel controls.

• Retains Factory Audio Controls

• Retains Compatible Volume Controls

• Retains Compatible Track / Seek Controls

• Retains Select Phone Pick-Up Functions

• Retains Select Phone Hang-Up Functions

• Built-In Pre-Programmed SWC Interface

• Exact button functionality may vary by vehicle and aftermarket receiver

SYNC & Voice Command Functions

The SWRFD-60E does not retain the complete factory SYNC system; however, according to the supplied product information, select voice-command and steering wheel phone-button functions can remain operational in compatible vehicles.

• Does Not Retain Full Ford SYNC Functionality

• Retains Select Voice Command Features in Compatible SYNC-Equipped Vehicles

• Retains Compatible Steering Wheel Phone Functions

• Functionality Varies by Vehicle & Aftermarket Receiver

Factory AUX Input Retention

• Retains Compatible Factory AUX-IN Jack

• Allows Continued Use of Factory Auxiliary Input in Supported Applications

• Aftermarket Receiver Must Support the Required Audio Input Connection

Retained Accessory Power – RAP

The interface retains compatible accessory power operation and provides a high-current accessory output for the aftermarket radio.

• Retains R.A.P. – Retained Accessory Power

• Provides 12-Volt Accessory Power

• Maximum Accessory Output: 10 Amps

• Designed to Support Compatible Aftermarket Radio Installations

Navigation & Vehicle Outputs

The SWRFD-60E provides important vehicle signals commonly required by aftermarket multimedia and navigation receivers.

• Parking Brake Output

• Reverse Gear Output

• Vehicle Speed Signal (VSS)

• Useful for Compatible Navigation Receivers

• Useful for Compatible Backup Camera Integration

Amplified & Non-Amplified Compatibility

• Compatible with Supported Non-Amplified Models

• Compatible with Supported Amplified Models

• Factory Audio Configuration Should Be Verified Before Installation

Micro-B USB Updatable

• Micro-B USB Update Port

• Supports Compatible Firmware Updates

• Helps Maintain Interface Compatibility When Updates Are Available

Vehicle Compatibility

Ford Edge

• 2011-2014 Ford Edge

Ford Escape

• 2013-Up Ford Escape

Ford Explorer

• 2011-2015 Ford Explorer

Ford F-150

• 2013-2014 Ford F-150

Ford Fiesta

• 2014-Up Ford Fiesta

Ford Focus

• 2012-2014 Ford Focus

Ford Transit

• 2015-Up Ford Transit

Ford Transit Connect

• 2014-2018 Ford Transit Connect

Important Compatibility Notes

• Vehicle must have a compatible 4-inch factory display

• Designed for the specific Ford applications listed above

• Retains compatible steering wheel audio controls

• Retains compatible factory AUX input

• Retains factory 4" display

• Does not retain the complete Ford SYNC system

• Select voice-command and phone-button functions may be retained in compatible SYNC-equipped vehicles

• Supports compatible amplified and non-amplified systems

• Factory feature retention may vary by vehicle, trim, factory radio, and aftermarket receiver

What's in this Package

• (1) CRUX SWRFD-60E Radio Replacement Interface with Steering Wheel Control Retention

Installation Notes

• Designed for compatible Ford vehicles equipped with the specified 4" factory screen.

• Accessory power output is rated up to 12 volts / 10 amps.

• Parking brake, reverse, and vehicle speed outputs are provided for compatible aftermarket receivers.

• The complete factory SYNC system is not retained, although select voice-command and phone-button functions may remain available as described above.

• Additional dash kits, antenna adapters, or radio-specific installation accessories may be required depending on the vehicle.

• Verify vehicle year, model, trim, factory screen size, amplifier configuration, and factory radio before installation.

• Professional installation is recommended.

• The supplied description refers to compatibility with select 2011-2025 Ford vehicles, while several applications are listed as “Up.” Use the detailed vehicle fitment and factory-screen requirements to confirm compatibility.
