Alpine S-A60M 600W S-Series Monoblock Class-D Amplifier
Pickup available at 1800 E Washington Blvd
Usually ready in 24 hours
Have Questions?
- Tel: +1 213 744 11 44
- Tel: +1 800 674 27 24
Brand: Alpine
Description
Alpine S-A60M S-Series Class-D Monoblock Amplifier – 600W RMS
The Alpine S-A60M S-Series Monoblock Amplifier delivers powerful, efficient bass performance for aftermarket subwoofer systems. Designed with Class-D technology, this compact mono amplifier produces up to 600 watts RMS while maintaining excellent efficiency and low distortion. Featuring a high damping factor, variable low-pass crossover, bass boost, and Alpine's advanced thermal management, the S-A60M is engineered for reliable performance and exceptional sound quality.
Key Features
🔊 600 WATTS RMS OUTPUT – Delivers up to 600W x 1 @ 2 Ohms and 400W x 1 @ 4 Ohms for powerful, clean bass.
⚡ HIGH-EFFICIENCY CLASS-D DESIGN – Compact amplifier design provides excellent power output while reducing heat and current draw.
🎚️ ADVANCED BASS CONTROLS – Variable low-pass filter (50–400 Hz) and adjustable bass boost (0–12 dB @ 50 Hz) allow precise system tuning.
🛡️ RELIABLE PROTECTION CIRCUITRY – Improved heatsink design and advanced protection circuits help prevent thermal shutdown for dependable operation.
🎛️ REMOTE BASS KNOB READY – Compatible with the optional Alpine RUX-KNOB.2 (sold separately) for convenient bass level adjustment.
General Features
-
Alpine S-Series Monoblock Class-D Amplifier
-
Class-D Mono Subwoofer Amplifier
-
CTA-2006 Compliant
-
Remote Bass Knob Compatible (RUX-KNOB.2 Sold Separately)
-
Remote Sensing Automatic Turn-On
-
Preamp RCA Inputs
-
Speaker-Level Inputs (Speaker Wire to RCA Adapter Required)
-
Variable Low-Pass Filter
-
Variable Bass Boost
-
Improved Heat Sink Design
-
Advanced Protection Circuitry
-
Authorized Dealer
-
1-Year Manufacturer Warranty
Specifications
-
Brand: Alpine
-
Model: S-A60M
-
Series: S-Series
-
Amplifier Class: Class-D
-
Channels: Mono
Power Output
-
400W x 1 @ 4 Ohms
-
600W x 1 @ 2 Ohms
Audio Performance
-
Frequency Response: 10 Hz – 400 Hz (±3 dB)
-
Signal-to-Noise Ratio: >85 dB (1W @ 4Ω), >105 dB (Rated Power @ 4Ω)
-
THD+N: ≤0.03%
-
Damping Factor: >1000
-
Low-Pass Filter: 50–400 Hz (24 dB/Octave)
-
Bass Boost: 0–12 dB @ 50 Hz
Electrical
-
Fuse Rating: 30A × 2
-
Recommended Power Wire: 4 Gauge
Dimensions
-
Width: 8"
-
Depth: 8"
-
Height: 2.25"
-
Approximate Weight: 11 lbs
Package Includes
-
Alpine S-A60M Monoblock Amplifier
-
Two Installed 30A ATO Fuses
-
Four Mounting Screws
-
2 mm Allen Wrench
-
Owner's Manual
-
Alpine Verification Certificate
-
Online Product Registration Information
Applications
-
Car Audio Subwoofer Systems
-
Mono Bass Amplification
-
Sealed & Ported Subwoofer Enclosures
-
Factory Audio Upgrades
-
Custom Car Audio Installations
